Łożysko z obudową SKF SYF 506

SKF SYF 506 – Bearing Housing Unit with Y-Bearing

Complete unit composed of a cast-iron housing and a Y-insert bearing. The housing has two mounting holes and is designed for a 30 mm shaft. It’s durable, easy to install, and designed for maintenance efficiency.

Technical Data:

• Manufacturer: SKF
• Type: Housing + Y-insert bearing unit
• Model: SYF 506
• Shaft diameter: 30 mm
• Housing material: Cast iron
• Number of mounting holes: 2
• Load ratings (YAR 206-2F): dynamic 19.5 kN, static 11.2 kN
• Weight: approx 0.90 kg

Applications:

• - Conveyor systems and transport lines
• - Agricultural machinery
• - Fans, pumps, auxiliary drives
• - Industrial machines with medium load
• - Supporting 30 mm shafts in various mechanical systems
