Airtac 3V210-08-NC 3/2-1/4-NC-220 V/230VAC Solenoid Valve

Airtac 3V210-08-NC 3/2-1/4-NC-220 V/230VAC Solenoid Valve

Technical data:

Type: 3/2-way pneumatic solenoid valve, normally closed (NC)

Series: 3V200 (AirTAC 3V)

Port size: 1/4″ (BSPT / NPT)

Working pressure range: 1.5–8 bar (0.15–0.8 MPa)

Medium: compressed air (filtered)

Coil voltage: available versions 24 VDC, 220 VAC, and other standard options (12 VDC, 24 VAC, 110 VAC)

Operating temperature: typically about -5 °C to +60 °C

Dimensions: width ~22 mm, height ~35 mm (with connector ~66 mm), length approx. 109–117 mm

Function: solenoid valve with spring return (NC)

Application: pneumatic control of actuators, automation systems, etc.
