5.7 inch Touch Panel Schneider Magelis XBTGT2120

5.7" Touch Panel Schneider Magelis XBTGT2120

Technical Specification

• Display: 5.7″ (QVGA) 320 × 240 pixels
• Display type: Backlit monochrome STN LCD, 16 gray levels
• Power supply: 24 V DC (range 19.2 … 28.8 V)
• Power consumption: approx. 26 W
• Panel and cut-out dimensions:
  • Enclosure width: 167.5 mm
  • Enclosure height: 135 mm
  • Depth: 59.5 mm
  • Cut-out dimensions (mounting panel): 156 × 123.5 mm (+1 / −0 tolerance)
• Mounting: Flush mounting, secured with spring clips or screws
• Interfaces and communication features:
  • SUB-D9 connector for COM1 (RS-232 / RS-422 / RS-485)
  • RJ45 connector for COM2 (RS-485) and other functions (depending on version)
• Operating temperature range: 0 … 50 °C
• Protection rating: Front IP65; rear IP20

Applications:

• Machine automation
• Industrial process control
• Assembly lines and robotics
• Energy and industrial installations
