Bearing with housing CX P205

Bearing with housing CX P205

CX P205 is a bearing unit consisting of a P205 type cast iron pillow block housing and a UC205 self-aligning bearing. It is designed for shafts with a diameter of 25 mm. Thanks to the spherical outer surface of the bearing and the ability to tilt, it compensates for shaft misalignment. It has set screws for mounting on the shaft and RS type seals. Used in agricultural, industrial, and transport machinery.

Dimensions and weight

• Bore diameter: 25 mm
• Mounting hole spacing: 125 mm
• Height to shaft axis: 33.3 mm
• Overall height: 64 mm
• Overall length: 140 mm
• Mounting hole diameter: 14 mm
• Weight: approx. 1.5 kg
